e bare wire and so as to include about one-half inch of the in-sulation. The details of the method of splicing the two wires together isshown in the left-hand portion of Fig. 600. The paper sleeve is tobe then slid over the sleeve as shown in the right-hand portion ofFig. 600. The reason for… … FIG. 6O2.-CABLE SPLICING. The two ends of the cable with a single pair thus connected isshown in Fig. 601. The joint in the wires should be so spaced that the joints in apair will not be directly opposite each other, and the joints inthe various pairs will be approximately evenly…
