Cycling art, energy and locomotion: a series of remarks on the development of bicycles, tricycles, and man-motor carriages (1889)
Scott, Robert Pittis · Philadelphia, J. B. Lippincott · leaf 294
aid wheels and connected to the rear wheel,for driving by an endless chain and sprocket-wheel,substantially as specified.^ The other drawing of this patent is used to illustratethe Rover rear-driver. I wish to call particular at-tention to the claim as given in above brief of specifi-cation, as it… … THE OPERATION VERY SIMPLE. 293 A. HOAKS VELOCIPEDE, The important part of the specification is as follows:^^ The shaft-gearing of these spur-wheels consists ofimpact roller motions, so that the crank centrally onthe shaft, within easy reach of the operator upon theseat and between the…
Cycling · Bicycles
Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
