ntact M, the electromotive force between M and Mmay be varied by steps of one-tenth of a volt, from 0 up to 1.5 volts.The wire D B is divided into 1100 equal parts. By moving thecontact point 1/ from 0 to 1100, the electromotive force between.M and M may be varied by infinitely small fractions of a… … Fig. C9. Diagram of Potentiometer Connections the fall of potential along A B. The contact points M and M arethen adjusted until the galvanometer shows that no current isflowing, when the value of the unknown electromotive force can beread from the position of the points M and M. In the diagram,the…
