268 PEACTICAL APPLIED ELECTRiClTy booster, whose action in the circuit is to produce an elec-trical pressure which acts in series with the main gen-erator pressure. When the electrical pressure of thebooster acts in opposition to the voltage of the maingenerator, it is called a negative booster.… … Fig. 225 to any other line, or itmay be engine -driven.There are a number of dif-ferent forms of boostersbut only two will be men-tioned hare, the series andthe shunt. The connectionof a series booster in a lineis shown in Fig. 227. Thebooster (B) is driven by acompound motor (M) con-nected as…
