Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 432

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 432
od from Fig. 88. The direction of the magnetic fluxproduced by the permanent magnet is downward from N to S,cutting the disk which rotates in the direction shown by the arrowA. This causes current to be generated in the disk, having a direc-tion shown by the arrow B. These currents divide and… … Fig. 89. Diagram of Commutator Type of Watt-hour Meter. A, is Armature; BB, Brushes; C, Commutator; CO, Friction Compensation Coil; D, Disk; Mj, M2, M3, M4, Drag Magnets; S, Shaft; SFC, SFCi, Series Field Coils; Tj, T,, T3, T4, Terminals; TW, TWj, Tension Weights for Brushes; W, Worm; WW, Worm…

Electrical engineering
