Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 121

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 121
f magnetism in the arma-ture core, which give rise to thecurrent, are produced by the rota-tion of a soft iron sleeve, B, whichpartially surrounds it, and is integralwith the hollow shaft, B\ whichalso carries the notched disk, B**,and the high-tension distributingdisk D. One end of the winding,A\… … EXPLOSIVE MOTOR POWER AND APPLIANCES. II9 one terminal of the condenser, the other terminal of the condenser andthe moving arm of the contact-breaker, B^, being grounded. Thesleeve, B, is slotted, and when the slots come opposite the poles of thefield magnet, the armature receives magnetism from…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
