Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 501
element that engages with thelarge dial hand. Therefore, as the meter progresses the maxicatorregister will carry forward this driving element, which in turn willcarry forw^ard the large friction dial hand at the same rate of speedand, consequently, at a speed directly proportional to the… … Fig. 135. Rear View of MaxicatorCourtesy of Chicago Electric Meter Company by means of a contact-making motor or clock, and will reset thedriving element to a zero position, but will leave the large frictionpointer, which it was driving, at the point it had reached when thesolenoid reset the…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
