is most easily accomplished by connecting the leadsfrom a voltmeter to the points between which the potential differ-ence is to be measured; the voltmeter forming a shunt circuit.Weston portable voltmeters are to be recommended for accuracyand permanency, the average error usually being less than… … Fig. 2.5. The connections are shown in Fig. 25. The potentiometerP consists of a number of coils all connected in series giving a highresistance. A sliding contact piece (7 is adjustable along P as inthe slide wire bridga and the resistance on eitlier side of O may 144 ELECTRICAL MEASUREMENTS. 43…
