eed ring armature Low-speed drum armature Low-speed ring armature in which df, = diameter of the shaft in the bearing; and k. = a con-stant depending upon the speed (see Table Xl\). The length ofthe shaft in bearings /^ varies from 2 to 4 times the diameter, de-pending upon the speed, the lower… … Fig. 148. Ring-Core Drum-Wound Armaturein Irocess of Construction spider attached to the shaft, the winding being placed in slots in thecircumference of the core, are called ring-core armatures to distin-guish them from ring-ivoimd armatures such as shown in Fig. 45.Fig. 148 represents a ring-core,…
