rm part of the spideritself (Fig. 149) or of a separate frame keyed to the skeleton pulley(Fig. 150). The spokes are usually elliptical in cross-section, andare generally made of cast iron or steel. They should be designedadequately to support and drive the armature. 140 CALCULATIONS 131 From a… … Fig. 149. Armature Driven by SpokeaForming Part of Spider in order that the safe workingstresses of the material utihzedmay not be exceeded. In theseformulas 6„ = Breadth of an arm par-allel to the shaft, in inches; /j = Safe working stress ofthe material for shearing, in lbs. per sq. in., which,…
