Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 217
Fig. 213.| Complete Armature of Crocker-Wheeler CompanyEngine-Type Generator with the pure barrel winding. It requires, however, special formers,and is applicable only to bar-wound armatures. On account of 188 DESIGN 179 … Fig, 214. Diagrammatic Representation of Barrel Winding
Electrical engineering
