Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 428

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 428
are expanded and move a device whichshort-circuits every commutator bar to one common ring of high 387 142 TYPES OF GENERATORS AND MOTORS conductivity and at the same time releases the tension on the carbonbrushes and pushes them back away from the commutator. Whenthe motor is stopped or slows down… … Fig. 184. Assemblei Stator Core and Housings of Form Q Induction MotorCourtesy of Crocker-Wheeler Company induction motors for 60 and 25 cycles, at the standard voltages.They embody the usual features of cast-iron frame, cast-steel lam-inations for stator core, form-wound interchangeable coils in…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
