insulated coils, and are then closed bymagnetic wedges which give mechanical strength and protection tothe coils, at the same time giving all the electrical advantages of aclosed-slot construction. The action of these magnetic wedges canbe seen from the following considerations, as shown in Figs.… … ilg. loo- Kjtdiot (, rockcr-WliL-eler liRluction Motor bridges E and the teeth B are fitted with the wood-stick wedges P,according to the usual open-slot practice. Considering the teethA, it will be noted that the magnetic bridge forms a shoe whichincreases the area from which the magnetic flux is…
