Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 115
Armature Teeth.—The teeth stamped in the corediscs are made in various shapes, depending largely on the ARMATURE CONSTRUCTION 327 method of securing the inductors in the slots against electro-magnetic drag and centrifugal force. The teeth may be cutwith their sides: 1. Inclined; 2. Projecting; 3.… … Fig. 355.—Western Electric slotted armature core. The laminations are of sheet steel, an-nealed and japanned. They are mounted directly on the,shaft, (except in the large sizes)and held in place by substantial end plates. Ques. What are the features of the projecting type oftooth? Ans. The…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
