Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 160
Fig. 66. Fig. 67. 131 132 HYDRAULIC MOTORS. § 86. faces, their lower extremities suggesting the form of a spoon,or scoop. The turbine, generally of cast iron, though some-times of bronze, is cast in a solid piece. In Fig. 67, V is theshaft of the turbine, while the smaller shaft W is intendedto…
Hydraulic machinery
