Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 181
ctedin series with the armature in such a way as to oppose the magnet-izing effect of the shunt winding and weaken tlie field, thus caus-ing the motor to speed up when the load is increased, as an offsetto the slowing-down effect of load. It was formerly used for obtaining very constant speed,… … Fig. 29. wiring Diagram for Compound-Wound Motor Connections coil becomes so great as to kill the field magnetism; and instead ofincreasing or keeping up its speed, the armature slows down orstops and is likely to burn out; whereas a plain shunt motor canincrease its power greatly for a minute or…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
