etimes expressed in pounds only, a radius of one footbeing understood or implied; but this is liable to cause confusion,because torque is not a force, but the moment of a force, and theradius of its action should always be given. EXAMPLE FOR PRACTICE If a motor has a torque of 40 pound-feet, what… … Fig. 7. Friction Brake. Fig. 7- P is the motor pulley, A and C blocks of hardwood clampedagainst it, the pressure being regulated by the wing-nuts e e. Thelever L, which may be of any convenient length, is counterbalancedby the weight w. When the pulley rotates in the direction of thearrow, the…
