Fig. 23. Connections of Motor-Starting Rheostat with No-Voltage and Overload Release. General Electric Company, Schenectady, N. Y. nection, as shovv-n in Fig. 22, this will either establish the currentthrough the field, or will merely bring the line voltage up to the start-ing box. 2. Move the… … RICHMOND POLYPHASE MOTOR BELTED TO A PUMP Courtesy of Richmond FJeclric Contpatiy DIRECT-CURRENT MOTORS 33 over and the resistance is short-circuited. The lever should then befirmly held by the retaining magnet. The entire operation should notconsume more than 15 to 30 seconds. If the motor does…
