by the WestinghouseL^ectric Company is shown with its cover removed in Fig. 93, andvith its case removed in Fig. 94. The shape of its electromagneticcircuit is shown diagrammatically in Fig. 95. That the resultantfield produced by the shunt and series coils is actually a shifting orf )tating one… … Disk MagnetClamping SCREWSA Magnet Supporting AND Adjusting Frame ClampingScrews B Light LoadAdjustingScrewsC Fig. 93. Typical Single-Phase Westiughouse Watt-Hour Meter The dotted lines in Fig. 95 show the main paths of the magneticflux produced by the two field windings, but the direction of…
