Wayne Single=Phase. Fig. 151 shows a 90-kilowatt 1,100-volt 8-pole single-phase belt-driven alternator manufactured by theFort Wayne Electric Company, of Fort Wayne, Indiana. It isdesigned to be driven at a speed of 900 revolutions per minute; hence 8. X 900the frequency of its electromotive force… … w a Sb 0 Jf O ^ o n o •^ 0) I s % 01 uni-directional current to the coarse wire coils of the compositefield winding. 160 ALTERNATING-CURRENT MACHINERY 149 The exciter is a shunt-wound 4-pole 2-kilowatt direct-currentgenerator running at a speed of 1,400 revolutions per minute. Itis shown belted to…
