Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 423
rotary taking power through its brushesand commutator from direct-current mains. The second machineis made to run as a regular rotary converter, taking its power fromthe collector rings (that is, alternating-current side) of machine No.1. Machine No. 2 then delivers its power in the form of direct… … CfeiJ Fig. 322. Wiring Diagram for Motor-Generator Method of Testing Rotary Converters and the alternating-current sides. If the machines are similar inevery respect, no appreciable current will flow between the two underthese circumstances. Each will run from the direct-current side,the two…
