th galvanized iron straps which areplaced at an angle of about 45 degrees. The braces are attachedto the cross-arms by carriage bolts and to the poles by lag screws.The cross-arms are bored to receive locust pins or iron bolts, uponwhich are mounted the glass or porcelain insulators. The upper 292… … Fig. 172. Diagram of Construction of Single-Track Interurban Trolley Road Concrete poles are moulded in a taper form somewhat similarin shape to wooden poles but of nearly square cross-section. Thecorners are chamfered to prevent chipping and to facilitate mould- 293 196 ELECTRIC RAILWAYS
