Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 338
Fig. 176. High-Tension PinInsulator Fig. 177. High-Tension PetticoatPin Insulator The shells are so designed as to form petticoats which furnisha long leakage path for the current over the surface and thus reducethe leakage. The insulator is made ofsuch size that the striking dis-tance from the…
Electrical engineering
