Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 347

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 347
Fig. 192. Line Construction on a Curve Using Five Poles POLE … PAJL___ TPOUfY W/P£: Fig. 193. Simple Curve Suspension Using Two Poles 304 ELECTRIC RAILWAYS 207 each hanger is attached a pull-over wire; and all of the pull-overwires terminate in a pole. Strain insulators are shown in these guy

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
