ugh anumber of helical springs. Fig. 260, which is a side elevation of thelocomotive, shows the arrangement of the principal parts. Fig. 261shows how the equipment looks with the cab and control apparatusremoved. Fig. 262 shows the field circuit with the brush holders.The compensating winding… … Fig. 263. Armature of Motor Shown in Fig. 261 The Grand Trunk Locomotive. The Grand Trunk Railroaduses a number of alternating-current locomotives in the St. Clairtunnel. Each locomotive is made in two separate units, each unithaving three axles with a 250 h.p., single-phase motor geared toit. The…
