ly, without having one interfere with the other. Each one ofthe circuits is suppHed with a regulating device V. R., so that anydesired current density is obtainable at the electrodes of the experi-mental devices I, II, III, and IV. The arrangement of the voltmetercircuits is such that the voltage… … 7>~6o mjTr^ £nd Cells D\jnam9 Fig. 26. Switchboard, Dynamo, and Battery Connections. of one ammeter A, separate readings of the current in each branchcircuit may be made, or the total current read. For example, withthe switches as shown in the figure, the current flowing through thefirst…
