Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 71

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 71
the term is still applied, even when the boardproper forms the smallest part of the equipment. The term switch-gear is now being introduced to cover all of the apparatus con-nected with the switching operations and the term switchboard isbeing reserved for the panels and their apparatus only.… … Extra /nsulatcon JC=-3-Jsa *-sysi/y^.^d, Three-Conductor Cable Without JointsfVipeci Joint, /nsl/l-att-or? ALberene Soapstone, Or Wood

Electrical engineering
