from 1 to 4. The pin on the vibx-ating lever from which the wrist-plate isdriven is taken to represent the travel of the valve. The real travelof the eccentric is propoi*tionately less, depending on the length o£the lever connections. THE CORLISS ENGINE. 345 Fi. 400 is a drawing of the wrist-i)late… … Fig. 401. As an example of the performance of engines of the compounilCorliss class, the following results aie given from a test of a pair of
