Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 199
ommonly associated with the Lodge-]\Iuirheadsystem, which is further characterized by being ungrounded, thelower capacity being in some cases placed several feet above the earth.One form of a Lodge-Muirhead sending and receiving station isdiagrammatically represented in Fig. 63, which makes clear… … Fig. 63. Lodge-Muirhead Sending and Receiving Circuits paratus used in conjimction with the Lodge-^^nirhead steel-diskcoherer previously described is not shown in tne drawing. Dr.Muirhead, endeavoring to render the system serviceable in connectionwith the ordinary forms of telegraphic signaling…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
