Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 204
Fig. 183. Connection of Wooden Joists andSteel Girder. 161 152 BUILDING SUPERINTENDENCE … Fig. 183. Effect of not bevelliug euds of Joists. that section, consists of posts at least 10 X 10 inches, spaced abouteight feet apart in the length of the mill and twenty-four or twenty-fivefeet across. Instead of a line of girders running lengthwise overthe line of posts, the floor beams are…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
