enerally recognized. The piece B is usuallymade to serve both as the top of the window and the bottom ofthe truss. Fig. 74 shows the fi-aming for the top of a window openingin a balloon-framed building, Avhere the ledger-board is partly sup-ported by the studs directly over the opening. Since the… … Fiff. 73. Truss over Window. 58 k
