Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 378
Top Chordof Truss Fig. 127. Gable Details for Corrugated Steel. Roof Steel … Purlin ^ SI/-Finish-••^ Angle Fig. 128, Gable Details for Corrugated Steel. 307 94 ROOF TRUSSES outstanding leg does not reach beyond the leg of the flange angle(see Fig. 123). This makes their size as shown in Fig. 122. Thecrane rail may be connected directly to these and the flange angles;or a…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
