eoreticallythe center of gravity lines of the members; it is more common practice,however, to use the pitch lines of the angles as the strain lines, as theselines do not varj materially from the center of gravity lines, and muchconfusion is thus saved. In heavy trusses, however, where the chordsare… … CD(N bh .0./ 284 STEEL CONSTRUCTION Many times the position of one or more panel points will be fixedby some features of construction such as a monitor or a hanger forshafting, or rod for balcony, etc., as illustrated by Figs. 2G7 and 280.Wherever such concentrated loads are fixed, there should be…
