icated, it is evident that tlie front, leffc-liand side and top will be light, and tlie bottom, back and right-hand side dark. On the plan, then, tlie shade lines will be theback edge 1 2 and the riglit-hand edge 2 3, because these edgesare between light faces and dark ones. On the elevation,…
