on, the others inclined to it. Another point of 141 50 MECHANICAL DRAWING tUfference is that oblique projection cannot be deduced fromorthographic projection, as is isometric. In oblique i)rojection all lines in the front face are shown intheir true lengths and in their true relation to one…
