Fig. 78. length. The horizontal distances from the upper left corner tothe dotted ^jerpendicular are then marked off on this line. Fromthese points verticals are drawn, and made equal in length to thedotted perpendiculars of Fig. 78, thus locating two corners of the end. LINE SHADING. In finely…
