ths for thediameter of the eye, and seven and five-tenths for the lower part ofthe volute. The volute may then be drawn. 67. The spiral or volute is composed of twelve quarter circlesdrawn from twelve different centres, which may be located in thefollowing manner. Having established, on a vertical… … 280
