Mechanical drawing. Prepared for the use of the students of the Massachusetts Institute of Technology, Boston, Mass (1887)

Faunce, Linus · Boston, W.J. Schofield, Printer · leaf 56

An illustration from Mechanical drawing. Prepared for the use of the students of the Massachusetts Institute of Technology, Boston, Mass, 1887, leaf 56 — smaller figure, and extend them. The divis-ions corresponding to 12 N are equal. The divisions OP andRL are each equal to one-half of 12 N. From 1 as a centreand radius IH draw the arc HS; from 2 as a centre and radius28 the arc ST; from centre 3 and radius 3T the arc TU; and50 proceed in the order… … 54 GEOMETRICAL PROBLEMS. Fillet Bead
