e base or springing line of the dome. Fig. 28 showsat A B C D such a square and circle. If the four walls whichform the sides of the square building are now continm^d upward,they will cut into the spherical segment whose base is representedby the circle, since this circle overhangs the square on… … Pig. 28. 873 62 THE ROMAN ORDERS as the semi-circular arches of radius 1-En and 50 parts, which coverthe doorways. A horizontal section taken through the dome at theelevation of the crowns of these circular segments will show acircle which (in plan) will be inscribed in the square formed by thefour…
