8 , _----^5f* ^. ^^f~~ ■^ 2 3 45 9 8 9 10 Fig. 83. Fig. 84. sections as shown in Fi^. 84 whose bases and heights are equal tosimilar numbered bases and heights in Fig. 83. For example, takethe distance 4 8 and place it as shown by 4 8 in Fig. 84, from whichpoints erect the vertical lines 4 4 and…
