Fig. 164 which are notched out as shown at M, thus allowing the drip to enterthe gutter N and discharge through the tube P. The foul air escapesunder the hood G as shown by the arrow. … Fig. 1G5. 220 SHEET METAL WORK 141 VARIOUS STYLES OF SKYLIGHTS In Fig. 165 is shown what is known as a single-pitch light, and is()lared on a curb made by the carpenter which has the desired pitch.
