Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 365
Fig. 283. Fig. 284. stretchout of the profile E. Through the numbered points of divi-sion and at right angles to 1 7, draw lines as shown, which intersectby lines drawn at right angles to C B from intersections of similarnumbers on the miter-lines a C and h B. Through the points thusobtained, trace…
