Fig. 312. Fig. 313. 311, draw lines from X to H to Iv to H^ to O, as shown, which repre-sents the pattern for one side. In Fig. 312 is shown a perspective view of a drop B miteringagainst the face of the bracket C as indicated at A. The principlesfor developing this problem are explained in Fig.…
