. Ventilation is obtainedby placing louwes at each end as shown at A. Fig. 167 shows askylight with a ridge ventilator. The corner bar C is called the hipbar; the small bar D, mitering against the corner bar, is called the jackbar, while E is called the common bar. Fig. 168 illustrates a hip… … Fig. 169. sashes in conservatories, greenhouses, etc., the same apparatus beingapplicable to both metal and wooden sashes. Fig. 170 shows a viewof a photographers skylight; if desired, the vertical sashes can be madeto open. In Fig. 171 is shown a flat extension skyhght at the rear of a storeor…
