Fig. 252. Fig. 253. slipped; then b forms a drip, and any water coming over the sill passesover the siding without danger of leaks; c is nailed in white lead to thewindow frame. Another use to which corrugated iron is put is to cover sheds andawnings. Sheets laid on wood are nailed in the usual… … preceding sections. In Fig. 254 is shown an awning over a store laidon angle iron supports. In work of this kind, to make a neat appear-ance, the sheets are cuived to conform to the iron bracket A. 222 CORNICE OVER BRICK BAY * An elevation and plan of a brick bay are shown in the illu.stration,…
