Fig. 188. Single Y with Side Outlet. single Y, by Fig. 177; double Y-branch, by Fig. 178; sanitary tee,by Fig. 179; and the double sanitary tee, by Fig. ISO. The tee anddouble tee shown are known as the sanitary pattern, on account of the 362 PLUMBING 139 The |-bend is also made … Fig. 184. Double Y-Branch with Trap-Screw Clean-Out. Fia-. 185. Bolted-Plate Cleau-Outon Soil-Pipe, curved branches, which direct die flow in the pipe Une somewhat in the same manner as does a Y-connection. Common tees and crosses are made in strictly right-anHe branches. with right and left…
