Fig. 189. Fig. 190. turned in one piece as shown in Fig. 193, the stock for which isprepared, with the inserted dowel pins all in position in the samemanner as described for the tee pattern, Fig. 188. The quarters, e, e, 121 no PATTERN MAKING e and e are clamped together two and two, and the ends… … Fig. 101. In Fig. 194, the core box for this double pattern is shown, andas will be seen the most difficult part of the work can be done in the lathe. Fig. 195 shows twopieces jointed and clamped to-gether which must be screwed tothe face-plate of the lathe andturned out to make the twocorners c…
