d, and is made steam-tight bv a stuffing-box, as shown. The pipes are connected at theflanges .1 and B. ^^^^ __ __ When pipes | ^ ^.^T^^^MTf^ pass through floors or parti-tions, the wood-work should beprotected by gal-V a n i z e d-i r o nsleeves having a diameter from | to 1 inch greater than the… … Slip-Joint Connection to Take Cai-e of Expansionand Contraction of Pipes.
