joints (B-Fig. 349) aregenerally easier to manipulatethan are. screwed joints. Theyafford ready means for disconnecting the various sections ofa piping-system. Their use is recommended in all steam-piping larger than 2.5-in. Note.—Flanges commonly form screwed joints with the pipe-ends.Hence, the… … Screwed SubsidiaryJoints- Fig. 349.—Screwed And Flanged JointsIn Steam-Piping. Sec. 435] STEAM-PIPING OF POWER PLANTS 369 ■Thread .■Chamfer 435. The Principal Methods of Attaching Flanges To Pipe-Ends are : (1) Threading. (2) Shrinking. (3) Flaring orlapping. (4) Welding. Threading (J, Fig. 350)…
