hod of Binding Boards Together from any side of the finished product. This is accomplished bycutting the same tenons and mortises as in the case of the simpledovetail joint, but not directly on the end of the pieces. Theyare so cut as to project at an angle of forty-five degrees, and thusto form a… … Fig. 87. Simple Dovetail Fig. 88. Lap Dovetail
